Migrating Legacy Databases: A Real-World n8n + PostgreSQL Story

┌─────────────────┐     ┌─────────────────┐     ┌─────────────────┐
│  Legacy System  │────▶│      n8n        │────▶│   PostgreSQL    │
│   (Source DB)   │     │  (Orchestrator) │     │   (Target DB)   │
└─────────────────┘     └─────────────────┘     └─────────────────┘
                               │
                               ▼
                        ┌─────────────────┐
                        │  Laravel API    │
                        │  (Validation)   │
                        └─────────────────┘

# docker-compose.yml
services:
  n8n:
    image: n8nio/n8n
    ports:
      - "5678:5678"
    volumes:
      - n8n_data:/home/node/.n8n
      - ./workflows:/workflows
    environment:
      - N8N_BASIC_AUTH_ACTIVE=true
      - EXECUTIONS_DATA_PRUNE=true
      - EXECUTIONS_DATA_MAX_AGE=168

  postgres:
    image: postgres:16
    volumes:
      - pg_data:/var/lib/postgresql/data
    environment:
      - POSTGRES_DB=migration_target

  legacy_db:
    # Read-only replica of legacy system
    ...

-- Analyze legacy table structures
SELECT
  table_name,
  column_name,
  data_type,
  is_nullable
FROM information_schema.columns
WHERE table_schema = 'public'
ORDER BY table_name, ordinal_position;

-- Find orphaned records
SELECT COUNT(*) as orphaned_orders
FROM orders o
LEFT JOIN customers c ON o.customer_id = c.id
WHERE c.id IS NULL;

-- Check for duplicates
SELECT email, COUNT(*) as count
FROM customers
GROUP BY email
HAVING COUNT(*) > 1;

-- Validate required fields
SELECT COUNT(*) as missing_names
FROM customers
WHERE name IS NULL OR name = '';

[Webhook Trigger]
       │
       ▼
[Query Legacy DB] ─── SELECT * FROM cust WHERE migrated = 0 LIMIT 1000
       │
       ▼
[Loop Over Items]
       │
       ▼
[Transform Data] ─── Clean, validate, map fields
       │
       ▼
[Check Existing] ─── Does customer exist in target?
       │
       ├── Yes ─▶ [Update Record]
       │
       └── No ──▶ [Insert Record]
       │
       ▼
[Mark Migrated] ─── UPDATE cust SET migrated = 1 WHERE id = ?
       │
       ▼
[Error Handler] ─── Log failures, notify team

// In Function node - process in batches
const batchSize = 1000;
const offset = $input.first().json.offset || 0;

return {
  json: {
    query: `SELECT * FROM customers OFFSET ${offset} LIMIT ${batchSize}`,
    nextOffset: offset + batchSize
  }
};

// Clean and transform customer data
return items.map(item => {
  const data = item.json;

  return {
    json: {
      id: data.cust_id,
      name: titleCase(data.cust_name?.trim() || 'Unknown'),
      email: data.cust_email?.toLowerCase().trim(),
      created_at: parseDate(data.created), // DD-MM-YYYY to ISO
      legacy_id: data.cust_id, // Keep reference
    }
  };
});

function titleCase(str) {
  return str.replace(/\w\S*/g, txt =>
    txt.charAt(0).toUpperCase() + txt.substr(1).toLowerCase()
  );
}

function parseDate(dateStr) {
  if (!dateStr) return new Date().toISOString();
  const [day, month, year] = dateStr.split('-');
  return new Date(year, month - 1, day).toISOString();
}

// Catch and log errors without stopping the workflow
try {
  // Migration logic
} catch (error) {
  // Log to error table
  await $node["Postgres"].execute({
    query: `INSERT INTO migration_errors (entity, record_id, error, created_at)
            VALUES ($1, $2, $3, NOW())`,
    values: ['customer', item.id, error.message]
  });

  // Continue with next item
  return [];
}

1. Customers (no dependencies)
2. Products (no dependencies)
3. Orders (depends on customers)
4. Order Items (depends on orders, products)
5. Invoices (depends on orders)

-- Mapping table
CREATE TABLE id_mappings (
  entity VARCHAR(50),
  legacy_id VARCHAR(50),
  new_id UUID,
  PRIMARY KEY (entity, legacy_id)
);

// Look up mapped IDs during migration
const customerMapping = await $node["Postgres"].execute({
  query: `SELECT new_id FROM id_mappings
          WHERE entity = 'customer' AND legacy_id = $1`,
  values: [item.legacy_customer_id]
});

if (!customerMapping.length) {
  throw new Error(`Customer ${item.legacy_customer_id} not yet migrated`);
}

item.customer_id = customerMapping[0].new_id;

// app/Http/Controllers/MigrationController.php
public function validateCustomer(Request $request)
{
    $validated = $request->validate([
        'name' => 'required|string|max:255',
        'email' => 'required|email|unique:customers,email',
        'created_at' => 'required|date',
    ]);

    // Additional business logic validation
    if ($this->isDuplicateByPhone($request->phone)) {
        return response()->json([
            'valid' => false,
            'error' => 'Duplicate phone number'
        ]);
    }

    return response()->json(['valid' => true]);
}

// app/Services/MigrationValidator.php
class MigrationValidator
{
    public function validateOrder(array $data): ValidationResult
    {
        $errors = [];

        // Order total must match sum of line items
        $calculatedTotal = collect($data['items'])
            ->sum(fn($item) => $item['quantity'] * $item['unit_price']);

        if (abs($calculatedTotal - $data['total']) > 0.01) {
            $errors[] = "Order total mismatch: expected {$calculatedTotal}, got {$data['total']}";
        }

        // Order date must be before or equal to ship date
        if ($data['ship_date'] && $data['order_date'] > $data['ship_date']) {
            $errors[] = "Ship date cannot be before order date";
        }

        // Customer must exist
        if (!Customer::where('legacy_id', $data['customer_id'])->exists()) {
            $errors[] = "Customer {$data['customer_id']} not found";
        }

        return new ValidationResult(empty($errors), $errors);
    }
}

-- Check referential integrity
SELECT o.id, o.customer_id
FROM orders o
LEFT JOIN customers c ON o.customer_id = c.id
WHERE c.id IS NULL AND o.created_at > NOW() - INTERVAL '1 hour';

-- Verify data completeness
SELECT
    COUNT(*) as total_orders,
    COUNT(CASE WHEN total IS NULL THEN 1 END) as missing_totals,
    COUNT(CASE WHEN customer_id IS NULL THEN 1 END) as missing_customers
FROM orders
WHERE migrated_at > NOW() - INTERVAL '1 hour';

-- Check for data truncation
SELECT id, name
FROM customers
WHERE LENGTH(name) = 255
AND migrated_at > NOW() - INTERVAL '1 hour';

-- Migration progress view
CREATE VIEW migration_progress AS
SELECT
  'customers' as entity,
  (SELECT COUNT(*) FROM legacy.cust) as total,
  (SELECT COUNT(*) FROM legacy.cust WHERE migrated = 1) as migrated,
  (SELECT COUNT(*) FROM migration_errors WHERE entity = 'customer') as errors
UNION ALL
SELECT
  'orders' as entity,
  (SELECT COUNT(*) FROM legacy.orders) as total,
  (SELECT COUNT(*) FROM legacy.orders WHERE migrated = 1) as migrated,
  (SELECT COUNT(*) FROM migration_errors WHERE entity = 'order') as errors;

CREATE TABLE migration_log (
    id SERIAL PRIMARY KEY,
    entity VARCHAR(50) NOT NULL,
    operation VARCHAR(20) NOT NULL, -- 'insert', 'update', 'skip', 'error'
    legacy_id VARCHAR(50),
    new_id UUID,
    details JSONB,
    duration_ms INTEGER,
    created_at TIMESTAMP DEFAULT NOW()
);

CREATE INDEX idx_migration_log_entity ON migration_log(entity);
CREATE INDEX idx_migration_log_created ON migration_log(created_at);
CREATE INDEX idx_migration_log_operation ON migration_log(operation);

// Log every operation in n8n Function node
const startTime = Date.now();

try {
    // ... migration logic ...

    await $node["Postgres"].execute({
        query: `INSERT INTO migration_log (entity, operation, legacy_id, new_id, duration_ms, details)
                VALUES ($1, $2, $3, $4, $5, $6)`,
        values: [
            'customer',
            existing ? 'update' : 'insert',
            item.legacy_id,
            newId,
            Date.now() - startTime,
            JSON.stringify({ source: item, transformed: transformed })
        ]
    });
} catch (error) {
    await $node["Postgres"].execute({
        query: `INSERT INTO migration_log (entity, operation, legacy_id, duration_ms, details)
                VALUES ($1, 'error', $2, $3, $4)`,
        values: ['customer', item.legacy_id, Date.now() - startTime, JSON.stringify({ error: error.message })]
    });
    throw error;
}

-- Estimate remaining time
SELECT
    entity,
    total,
    migrated,
    ROUND(100.0 * migrated / total, 2) as percent_complete,
    ROUND(AVG(duration_ms)) as avg_duration_ms,
    ROUND((total - migrated) * AVG(duration_ms) / 1000 / 60, 1) as estimated_minutes_remaining
FROM migration_progress mp
JOIN migration_log ml ON ml.entity = mp.entity
WHERE ml.created_at > NOW() - INTERVAL '10 minutes'
GROUP BY entity, total, migrated;

-- Rollback script
DELETE FROM customers WHERE legacy_id IS NOT NULL;
UPDATE legacy.cust SET migrated = 0;
TRUNCATE migration_errors;

-- Before migration
CREATE TABLE customers_backup_20250114 AS SELECT * FROM customers;
CREATE TABLE orders_backup_20250114 AS SELECT * FROM orders;

-- Rollback
TRUNCATE customers;
INSERT INTO customers SELECT * FROM customers_backup_20250114;

-- Create rollback tracking
CREATE TABLE rollback_batches (
    batch_id UUID PRIMARY KEY DEFAULT gen_random_uuid(),
    entity VARCHAR(50),
    started_at TIMESTAMP,
    completed_at TIMESTAMP,
    record_count INTEGER,
    status VARCHAR(20) DEFAULT 'in_progress'
);

-- Tag records with batch ID
ALTER TABLE customers ADD COLUMN migration_batch_id UUID;

-- Rollback specific batch
DELETE FROM customers WHERE migration_batch_id = 'batch-uuid-here';
UPDATE rollback_batches SET status = 'rolled_back' WHERE batch_id = 'batch-uuid-here';

// In n8n - write to both old and new systems
const newRecord = await $node["NewPostgres"].insert(transformed);
await $node["LegacyDB"].update({
    query: `UPDATE cust SET synced_id = $1, last_synced = NOW() WHERE cust_id = $2`,
    values: [newRecord.id, item.legacy_id]
});

// n8n Function node with error handling
const results = [];
const failures = [];

for (const item of items) {
    try {
        const result = await migrateRecord(item);
        results.push(result);
    } catch (error) {
        failures.push({
            item,
            error: error.message,
            timestamp: new Date().toISOString()
        });
    }
}

// Store failures for later retry
if (failures.length > 0) {
    await $node["Postgres"].execute({
        query: `INSERT INTO migration_dlq (entity, payload, error, created_at)
                SELECT 'customer', payload::jsonb, error, created_at::timestamp
                FROM jsonb_array_elements($1::jsonb) WITH ORDINALITY AS t(payload, error, created_at)`,
        values: [JSON.stringify(failures)]
    });
}

return results;

// Exponential backoff retry
async function migrateWithRetry(item, maxRetries = 3) {
    for (let attempt = 1; attempt <= maxRetries; attempt++) {
        try {
            return await migrateRecord(item);
        } catch (error) {
            if (attempt === maxRetries) throw error;

            const delay = Math.pow(2, attempt) * 1000; // 2s, 4s, 8s
            await new Promise(resolve => setTimeout(resolve, delay));

            console.log(`Retry ${attempt}/${maxRetries} for ${item.id} after ${delay}ms`);
        }
    }
}

// Track failure rate
const FAILURE_THRESHOLD = 0.05; // 5%
const WINDOW_SIZE = 100;

let recentResults = [];

function recordResult(success) {
    recentResults.push(success);
    if (recentResults.length > WINDOW_SIZE) {
        recentResults.shift();
    }

    const failureRate = recentResults.filter(r => !r).length / recentResults.length;

    if (failureRate > FAILURE_THRESHOLD && recentResults.length >= WINDOW_SIZE) {
        throw new Error(`Circuit breaker tripped: ${(failureRate * 100).toFixed(1)}% failure rate`);
    }
}

// n8n webhook to Slack
if (failures.length > 10) {
    await $node["Slack"].send({
        channel: '#migration-alerts',
        text: `:warning: Migration alert: ${failures.length} failures in last batch`,
        attachments: [{
            color: 'warning',
            fields: [
                { title: 'Entity', value: 'customers', short: true },
                { title: 'Failures', value: failures.length.toString(), short: true },
                { title: 'Sample Error', value: failures[0].error }
            ]
        }]
    });
}

-- Create test dataset with realistic distribution
CREATE TABLE test_customers AS
SELECT * FROM legacy.cust
WHERE
    -- Include edge cases
    cust_id IN (
        SELECT cust_id FROM legacy.cust WHERE email IS NULL LIMIT 10
    )
    OR cust_id IN (
        SELECT cust_id FROM legacy.cust WHERE LENGTH(cust_name) > 100 LIMIT 10
    )
    -- Plus random sample
    OR random() < 0.01
LIMIT 1000;

// tests/Feature/MigrationTest.php
class MigrationTest extends TestCase
{
    public function test_customer_transformation_preserves_data()
    {
        $legacy = [
            'cust_id' => '12345',
            'cust_name' => '  john DOE  ',
            'cust_email' => '[email protected]',
            'created' => '15-03-2020'
        ];

        $result = (new CustomerTransformer())->transform($legacy);

        $this->assertEquals('12345', $result['legacy_id']);
        $this->assertEquals('John Doe', $result['name']);
        $this->assertEquals('[email protected]', $result['email']);
        $this->assertEquals('2020-03-15T00:00:00.000Z', $result['created_at']);
    }

    public function test_migration_handles_null_email()
    {
        $legacy = [
            'cust_id' => '99999',
            'cust_name' => 'No Email Customer',
            'cust_email' => null,
            'created' => '01-01-2015'
        ];

        $result = (new CustomerTransformer())->transform($legacy);

        $this->assertNull($result['email']);
    }

    public function test_migration_rollback_works()
    {
        // Run migration
        $this->artisan('migrate:customers --batch=test-batch');

        // Verify data exists
        $this->assertDatabaseHas('customers', ['legacy_id' => '12345']);

        // Rollback
        $this->artisan('migrate:rollback --batch=test-batch');

        // Verify data removed
        $this->assertDatabaseMissing('customers', ['legacy_id' => '12345']);
    }
}

// n8n dry run mode
const DRY_RUN = $input.first().json.dryRun || false;

const transformed = transformCustomer(item);
const validation = await validateCustomer(transformed);

if (!validation.valid) {
    return { status: 'invalid', errors: validation.errors };
}

if (DRY_RUN) {
    return {
        status: 'dry_run',
        would_insert: transformed,
        validation: 'passed'
    };
}

// Actual insert
const result = await insertCustomer(transformed);
return { status: 'success', id: result.id };

If ALL true, proceed:
- Error rate < 1%
- Row count variance < 0.1%
- No critical validation failures
- Spot checks pass
- Stakeholder sign-off received

If ANY false, rollback:
- Execute rollback runbook
- Notify stakeholders
- Schedule post-mortem
