Building Production Electron Apps with Vue 3 and Azure SSO

After shipping three production Electron applications, I've learned that building a "real" desktop app is very different from following a tutorial. This guide covers the patterns and pitfalls I've encountered, with a focus on enterprise requirements like Azure AD authentication.

Why Electron in 2025?

Before diving in, let's address the elephant in the room: Electron has a reputation for being bloated. However, for certain use cases, it remains the best choice:

Enterprise integration - When you need deep OS integration with web-based systems
Cross-platform requirement - Ship to Windows and macOS from one codebase
Existing web expertise - Your team knows Vue/React, not Swift or C#
Rapid iteration - Web tooling enables fast development cycles

If your app is purely offline or doesn't need web tech, consider native alternatives. But for bridging web systems to the desktop, Electron still wins.

Project Architecture

The most important decision is your process architecture. Electron runs multiple processes:

┌─────────────────────────────────────────────┐
│                 Main Process                │
│  (Node.js - full system access)             │
├─────────────────────────────────────────────┤
│               Preload Scripts               │
│  (Bridge - controlled exposure)             │
├─────────────────────────────────────────────┤
│              Renderer Process               │
│  (Chromium - Vue 3 app, sandboxed)         │
└─────────────────────────────────────────────┘

Never let your renderer process access Node.js APIs directly. This is the #1 security mistake in Electron apps.

Recommended Structure

packages/
├── main/
│   ├── src/
│   │   ├── index.ts        # Entry point
│   │   ├── ipc/            # IPC handlers
│   │   ├── services/       # Auth, updates, etc.
│   │   └── windows/        # Window management
│   └── tsconfig.json
├── preload/
│   ├── src/
│   │   └── index.ts        # Exposed APIs
│   └── tsconfig.json
└── renderer/
    ├── src/
    │   ├── App.vue
    │   ├── components/
    │   └── stores/         # Pinia stores
    └── tsconfig.json

Each package has its own TypeScript config and build process. This enforces separation and catches cross-boundary mistakes at compile time.

Setting Up Azure AD Authentication

Enterprise apps need SSO. Here's how to implement Azure AD auth properly in Electron.

1. Register Your App in Azure

In the Azure Portal:

Go to Azure Active Directory > App registrations
Create a new registration
Set redirect URI to http://localhost (for development)
Under Authentication, enable "Allow public client flows"
Note your Application (client) ID and Directory (tenant) ID

2. Install MSAL

npm install @azure/msal-node

Note: Use msal-node in the main process, not msal-browser. The browser version won't work correctly in Electron's main process.

3. Implement the Auth Service

// packages/main/src/services/auth.ts
import { PublicClientApplication, AuthenticationResult } from '@azure/msal-node'
import { BrowserWindow } from 'electron'

const MSAL_CONFIG = {
  auth: {
    clientId: process.env.AZURE_CLIENT_ID!,
    authority: `https://login.microsoftonline.com/${process.env.AZURE_TENANT_ID}`,
  },
}

const SCOPES = ['User.Read', 'openid', 'profile', 'email']

export class AuthService {
  private pca: PublicClientApplication
  private account: AccountInfo | null = null

  constructor() {
    this.pca = new PublicClientApplication(MSAL_CONFIG)
  }

  async login(parentWindow: BrowserWindow): Promise<AuthenticationResult> {
    // Try silent auth first (cached tokens)
    const accounts = await this.pca.getTokenCache().getAllAccounts()

    if (accounts.length > 0) {
      try {
        return await this.pca.acquireTokenSilent({
          account: accounts[0],
          scopes: SCOPES,
        })
      } catch {
        // Silent auth failed, continue to interactive
      }
    }

    // Interactive login required
    return this.interactiveLogin(parentWindow)
  }

  private async interactiveLogin(
    parentWindow: BrowserWindow
  ): Promise<AuthenticationResult> {
    // Open auth window
    const authWindow = new BrowserWindow({
      parent: parentWindow,
      modal: true,
      width: 500,
      height: 600,
      webPreferences: {
        nodeIntegration: false,
        contextIsolation: true,
      },
    })

    const authUrl = await this.pca.getAuthCodeUrl({
      scopes: SCOPES,
      redirectUri: 'http://localhost',
    })

    return new Promise((resolve, reject) => {
      // Listen for redirect
      authWindow.webContents.on('will-redirect', async (event, url) => {
        if (url.startsWith('http://localhost')) {
          event.preventDefault()

          const urlParams = new URL(url).searchParams
          const code = urlParams.get('code')

          if (code) {
            try {
              const result = await this.pca.acquireTokenByCode({
                code,
                scopes: SCOPES,
                redirectUri: 'http://localhost',
              })
              this.account = result.account
              authWindow.close()
              resolve(result)
            } catch (error) {
              authWindow.close()
              reject(error)
            }
          }
        }
      })

      authWindow.loadURL(authUrl)
    })
  }

  async getAccessToken(): Promise<string | null> {
    if (!this.account) return null

    try {
      const result = await this.pca.acquireTokenSilent({
        account: this.account,
        scopes: SCOPES,
      })
      return result.accessToken
    } catch {
      return null
    }
  }

  async logout(): Promise<void> {
    const accounts = await this.pca.getTokenCache().getAllAccounts()
    for (const account of accounts) {
      await this.pca.getTokenCache().removeAccount(account)
    }
    this.account = null
  }
}

4. Expose Auth to Renderer via Preload

// packages/preload/src/index.ts
import { contextBridge, ipcRenderer } from 'electron'

contextBridge.exposeInMainWorld('electronAPI', {
  auth: {
    login: () => ipcRenderer.invoke('auth:login'),
    logout: () => ipcRenderer.invoke('auth:logout'),
    getToken: () => ipcRenderer.invoke('auth:getToken'),
    onAuthStateChange: (callback: (user: User | null) => void) => {
      ipcRenderer.on('auth:stateChange', (_, user) => callback(user))
    },
  },
})

5. Handle IPC in Main Process

// packages/main/src/ipc/auth.ts
import { ipcMain, BrowserWindow } from 'electron'
import { authService } from '../services/auth'

export function registerAuthHandlers(mainWindow: BrowserWindow) {
  ipcMain.handle('auth:login', async () => {
    try {
      const result = await authService.login(mainWindow)
      mainWindow.webContents.send('auth:stateChange', {
        name: result.account?.name,
        email: result.account?.username,
      })
      return { success: true }
    } catch (error) {
      return { success: false, error: error.message }
    }
  })

  ipcMain.handle('auth:logout', async () => {
    await authService.logout()
    mainWindow.webContents.send('auth:stateChange', null)
    return { success: true }
  })

  ipcMain.handle('auth:getToken', async () => {
    return authService.getAccessToken()
  })
}

6. Use in Vue Components

<script setup lang="ts">
import { ref, onMounted } from 'vue'

const user = ref<User | null>(null)
const isLoading = ref(false)

onMounted(() => {
  window.electronAPI.auth.onAuthStateChange((newUser) => {
    user.value = newUser
  })
})

async function handleLogin() {
  isLoading.value = true
  try {
    await window.electronAPI.auth.login()
  } finally {
    isLoading.value = false
  }
}
</script>

<template>
  <div v-if="user">
    Welcome, {{ user.name }}
    <button @click="window.electronAPI.auth.logout()">Logout</button>
  </div>
  <button v-else @click="handleLogin" :disabled="isLoading">
    {{ isLoading ? 'Signing in...' : 'Sign in with Microsoft' }}
  </button>
</template>

Auto-Updates

Production apps need automatic updates. Electron-builder makes this straightforward.

Configuration

# electron-builder.yml
appId: com.company.yourapp
productName: Your App
publish:
  provider: github
  owner: your-org
  repo: your-app
  releaseType: release

Update Service

// packages/main/src/services/updater.ts
import { autoUpdater } from 'electron-updater'
import { BrowserWindow } from 'electron'

export function initAutoUpdater(mainWindow: BrowserWindow) {
  autoUpdater.autoDownload = true
  autoUpdater.autoInstallOnAppQuit = true

  autoUpdater.on('update-available', (info) => {
    mainWindow.webContents.send('update:available', info.version)
  })

  autoUpdater.on('update-downloaded', (info) => {
    mainWindow.webContents.send('update:ready', info.version)
  })

  autoUpdater.on('error', (error) => {
    console.error('Update error:', error)
  })

  // Check for updates every hour
  setInterval(() => {
    autoUpdater.checkForUpdates()
  }, 60 * 60 * 1000)

  // Initial check
  autoUpdater.checkForUpdates()
}

State Persistence with Pinia

Keep user state across app restarts:

// packages/renderer/src/stores/settings.ts
import { defineStore } from 'pinia'

export const useSettingsStore = defineStore('settings', {
  state: () => ({
    theme: 'system' as 'light' | 'dark' | 'system',
    sidebarCollapsed: false,
    recentFiles: [] as string[],
  }),

  actions: {
    addRecentFile(path: string) {
      this.recentFiles = [
        path,
        ...this.recentFiles.filter((p) => p !== path),
      ].slice(0, 10)
    },
  },

  persist: true, // pinia-plugin-persistedstate
})

Common Pitfalls

1. Memory Leaks

Electron apps are notorious for memory leaks. Watch out for:

Event listeners not being removed
Large objects held in closures
IPC handlers accumulating

// Bad - accumulates listeners
ipcMain.on('some-event', handler)

// Good - clean up when window closes
mainWindow.on('closed', () => {
  ipcMain.removeHandler('some-event')
})

2. Security Vulnerabilities

Never do this:

// DANGEROUS - allows arbitrary code execution
new BrowserWindow({
  webPreferences: {
    nodeIntegration: true,
    contextIsolation: false,
  },
})

Always use context isolation and preload scripts.

3. Blocking the Main Process

Long operations in main process freeze the entire app:

// Bad - blocks everything
ipcMain.handle('process-file', (_, path) => {
  return fs.readFileSync(path) // Sync = blocking
})

// Good - async and non-blocking
ipcMain.handle('process-file', async (_, path) => {
  return fs.promises.readFile(path)
})

Build and Distribution

macOS Code Signing

For distribution outside the App Store, you need:

Developer ID Application certificate
Notarization with Apple

# electron-builder.yml
mac:
  hardenedRuntime: true
  entitlements: build/entitlements.mac.plist
  entitlementsInherit: build/entitlements.mac.plist

afterSign: scripts/notarize.js

Windows Code Signing

Windows SmartScreen requires an EV certificate or reputation building:

# electron-builder.yml
win:
  certificateSubjectName: 'Your Company Name'
  signAndEditExecutable: true

Conclusion

Building production Electron apps requires attention to security, performance, and user experience. The key takeaways:

Enforce process separation - Never give renderer access to Node
Use MSAL-node for Azure auth - The browser version doesn't work correctly
Implement auto-updates early - Users expect seamless updates
Persist state thoughtfully - Pinia with persistence works great
Test on both platforms - Differences will surprise you

The combination of Vue 3's reactivity, TypeScript's safety, and Electron's capabilities makes for a powerful development experience - once you understand the architecture.

Have questions about Electron development? Get in touch - I'm always happy to discuss desktop app architecture.
